SuperATV Can-Am Maverick 8" Portal Gear Lift

To avoid any fitment issues, please make sure to select the exact year, make and model of your vehicle. If you are unsure, please reach out to us for assistance prior to purchasing. Not that this part is built-to-order and NON-RETURNABLE. This part must be installed by a licensed professional to avoid any issues related to the complex installation

Gear Down and Go Big
SuperATV's GDP 8" Portal Gear Lift is geared down so you can go big. It gives you a lift and a 45% gear reduction in one box. Get the clearance to run bigger tires and the torque you need to turn them. The lift and gear reduction are in the hub, so they maintain suspension geometry and reduce drivetrain stress. Big clearance, big torque, and big tires — with GDP you can unleash the beast.

Perfect for Mud
With 8" portals and a 45% gear reduction, you get clearance for huge tires and a massive boost in torque. With all that torque, big tires won't slow you down, and with all that lift, you'll roll through bounty holes like they're mud puddles. Our 8" portals are made for mud.

Perfect for Rocks
Get tons of torque to crawl over any rock or boulder you can find by installing an 8" GDP portal box with a 45% gear reduction. More power means you can take on bigger boulders and steeper shelves. With all that clearance, you can install huge tires and never get high-centered. Clearance and power open a world of rock crawling possibilities.

Better Gears
Our gears are precision ground and made with 9310 billet steel alloy. They're designed to take all the torque and abuse you can give them without chipping teeth or blowing up. Our precise design and manufacturing mean they're cool and quiet even when you're hammering down the throttle in the mud hole.

Billet Housings
Choose billet or cast aluminum housings to finish your portals. Our billet housings are CNC-machined right here in Madison, Indiana and give you increased strength and consistency over cast. Plus, there's nothing quite like spraying the mud off your pristine billet housings.

Reinforce Your Frame with a Frame Stiffener
We highly recommend running a SuperATV Frame Stiffener with your 8" Portal Gear Lift. A frame stiffener reinforces your frame enough to let you ride your 8" portals with monster tires and no worries.

Portal Gear Reduction Recommendations

FEATURES

• Available with billet or cast aluminum housing
• Cool, quiet, precision ground gears made from 9310 alloy billet steel
• 1.5 in. forward and rear offset
• Increases width by 4 in. per side (8 in. total)
• 1.5 in. diameter 4340 hardened steel driveshaft
• Housings use advanced gaskets and rubber O-rings that don’t let anything through
• Universal hubs can be set up to work with the following bolt patterns: 4/156, 4/137, 4/115, and 4/110
• Gear reduction reduces stress on your drivetrain
